Network technology
GSM / CDMA / HSPA / EVDO / LTE
Network 2g bands
GSM 850 / 900 / 1800 / 1900- SIM 1 & SIM 2 (dual-SIM model only)CDMA 800 / 1900- USA
Network 3g bands
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100- Global, USACDMA2000 1xEV-DO- USA
Network 4g bands
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 38, 39, 40, 41, 66- Global1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 46, 66, 71- USA
Network speed
HSPA 42.2/5.76 Mbps, LTE-A (7CA) Cat20 2000/150 Mbps
Launch announced
2019, February 20
Launch status
Available. Released 2019, March 08
Body dimensions
157.6 x 74.1 x 7.8 mm (6.20 x 2.92 x 0.31 in)
Body weight
175 g / 198 g (ceramic) (6.17 oz)
Body build
Glass front (Gorilla Glass 6), glass back (Gorilla Glass 5), aluminum frameGlass front (Gorilla Glass 6), ceramic back, ceramic frame
Body sim
Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)Samsung Pay (Visa, MasterCard certified) IP68 dust/water resistant (up to 1.5m for 30 mins)
Display type
Dynamic AMOLED capacitive touchscreen, 16M colors
Display size
6.4 inches, 103.8 cm2 (~88.9% screen-to-body ratio)
Display resolution
1440 x 3040 pixels, 19:9 ratio (~522 ppi density)
Display protection
Corning Gorilla Glass 6HDR10+ Always-on display
Platform os
Android 9.0 (Pie), upgradable to Android 10, One UI 2
Platform chipset
Exynos 9820 (8 nm)- EMEA/LATAMQualcomm SM8150 Snapdragon 855 (7 nm)- USA/China
Platform cpu
Octa-core (2x2.73 GHz Mongoose M4 & 2x2.31 GHz Cortex-A75 & 4x1.95 GHz Cortex-A55)- EMEA/LATAMOcta-core (1x2.84 GHz Kryo 485 & 3x2.42 GHz Kryo 485 & 4x1.78 GHz Kryo 485)- USA/China
Platform gpu
Mali-G76 MP12- EMEA/LATAMAdreno 640- USA/China
Memory card slot
microSDXC (uses shared SIM slot)- dual SIM model only
Memory internal
128GB 8GB RAM, 512GB 8GB RAM, 1TB 12GB RAMUFS 2.1
Main camera features
LED flash, auto-HDR, panorama
Main camera video
4K@60fps (no EIS), 4K@30fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS
Selfie camera features
Dual video call, Auto-HDR
Selfie camera video
4K@30/60fps, 1080p@30fps
Sound loudspeaker
Yes, with stereo speakers
Sound 35mm jack
Yes32-bit/384kHz audio Tuned by AKG
Comms wlan
Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct, hotspot
Comms bluetooth
5.0, A2DP, LE, aptX
Comms gps
Yes, with A-GPS, GLONASS, BDS, GALILEO
Comms nfc
Yes
Comms radio
FM radio (USA & Canada only)
Comms usb
3.1, Type-C 1.0 reversible connector
Features sensors
Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2ANT+ Bixby natural language commands and dictation Samsung DeX (desktop experience support)
Battery
Non-removable Li-Ion 4100 mAh battery
Battery charging
Fast charging 15W USB Power Delivery 2.0 Fast Qi/PMA wireless charging 15W Reverse wireless charging 9W
Misc colors
Prism White, Prism Black, Prism Green, Prism Blue, Canary Yellow, Flamingo Pink, Ceramic Black, Ceramic White, Cardinal Red, Smoke Blue
Misc models
SM-G975F, SM-G975U, SM-G975W, SM-G975U1, SM-G9750, SM-G975N, SM-G975X
Misc sar
1.06 W/kg (head) & & 1.03 W/kg (body) & &
Misc sar eu
0.52 W/kg (head) & & 1.58 W/kg (body) & &
Misc price
$464.97 / 635.00 / 599.99 / 55,999
Tests performance
AnTuTu: 333736 (v7), 399901 (v8) GeekBench: 10387 (v4.4), 2190 (v5.1) GFXBench: 23fps (ES 3.1 onscreen)
Tests display
Contrast ratio: Infinite (nominal), 4.514 (sunlight)
Tests camera
Photo / Video
Tests loudspeaker
-24.7 LUFS (Very good)
Tests battery life
Endurance rating 91h
